Telefunken TF51 Three-Pattern Large-Diaphragm Tube Condenser Microphone

Manufacturer’s Description

The TF51 is a fresh take on the “Austrian” microphone sound associated with the legendary TELEFUNKEN ELA M 251E and C12. The TF51 continues this legacy, exhibiting a smooth midrange and airy top end and capturing every nuance in pleasant detail. The TF51 is a reliable first choice for stand out vocals, acoustic instruments, and percussion. Similar to the 251E and C12, the TF51 features a CK12-style edge terminated capsule, 6072A vacuum tube, and custom-made Haufe transformer. The combination of these components provides a beautifully open and smooth sonic profile, with a certain level of articulation that can only be described as lifelike.

Features

• Airy and open top end, reminiscent of the ELA M 251E
• Balanced low end and natural midrange
• Cardioid, Omni, and Figure 8 polar pattern selection
• CK12-style capsule and German-made Haufe transformer
• TELEFUNKEN Elektroakustik 6072A vacuum tube
• Designed and hand assembled in the USA
• Recommended Applications: Vocals, Acoustic Guitar, Violin, Drum Overheads

Each system includes:

• TF51 Microphone
• M 903 Power Supply
• M 803 Tube Microphone Cable – 7m
• ZC03 Zipper Case
• M 703 Shock Mount
• M 782 Stand Mount
• MS01 Microphone Sleeve

Specifications

• Type: Vacuum Tube Condenser
• Polar Pattern: Cardioid, Omnidirectional, Figure-8
• Frequency Range: 20 Hz – 20 kHz, ±3 dB
• Power Source: External Power Supply
• Capsule: TK51 Edge Terminated Large Diaphragm
• Tube: TELEFUNKEN Elektroakustik 6072A
• Transformer: Haufe T31
• Sensitivity: 19 mV/Pa, ±1 dB
• THD at 1kHZ at 1Pa (Amplifier): < 0.4%
• Output Impedance: < 300 Ω
• Maximum SPL (for 1% THD): 128 dB
• S/N Ratio: 86 dBA
• Self Noise (Amplifier): 8 dBA
• Dimensions: 200 mm L x 46 mm Dia
• Weight: 615 g
• Included Accessories: Tube Mic Cable, Power Supply, Shock Mount, Stand Mount, Mic Sleeve, Carrying Case
