Description
Manufacturer’s Description
The TF11 is a unique design and a new take on the large diaphragm condenser microphone. Blending an Austrian-inspired voicing similar to the legendary C12 with modern FET high performance, the TF11 features a beautifully open and detailed frequency response with exceptionally fast transient response, high SPL handling, and low self-noise. The compact, Cardioid-only TF11 is versatile, portable, and dependable for all recording environments from home to studio to stage. Countless sources including voice, drum overheads, and acoustic instruments shine when captured with this microphone. Hand-assembled in the USA, the TF11 features a CK12-style edge terminated capsule, premium through-hole components, and a custom UK-made OEP/Carnhill output transformer.
Features
- Open and detailed tone with fast transient response
- Compact size suitable for all recording environments
- Fixed Cardioid polar pattern
- High SPL handling, low noise phantom-powered FET amplifier
- CK12-style capsule and UK-made OEP/Carnhill transformer
- Designed and assembled by hand in the USA
- Recommended Applications: Vocals, Drum Overheads, Acoustic Guitar, Live Sound
Each system includes
- TF11 Microphone
- MC11 Microphone Case
- M 703 Shock Mount
- M 782 Stand Mount
- MS01 Microphone Sleeve
Specifications
- Type: FET Condenser
- Polar Pattern: Cardioid
- Frequency Range: 20 Hz – 20 kHz, ±3 dB
- Power Source: +48V Phantom Power
- Capsule: TK51S – Edge Terminated Large Diaphragm, Single Membrane
- Transformer: OEP/Carnhill T218
- Sensitivity: 14 mV/Pa, ±1 dB
- THD at 1kHZ at 1Pa (Amplifier): 0.005%
- Output Impedance: < 200 Ω
- Maximum SPL (for 1% THD): > 135 dB
- S/N Ratio: 90 dBA
- Self Noise (Amplifier): 4 dBA
- Dimensions: 175 mm L x 46 mm Dia
- Weight: 545 g
- Included Accessories: Shock Mount, Stand Mount, Mic Sleeve, Mic Case
| Condition | New |
|---|
