Supro Chorus All-Analog Full-Stereo 9-Volt Pedal w/ Dimension Knob

Manufacturer’s Description

The Supro Chorus is an all-analog, full-stereo modulation stompbox that uses a pair of genuine MN3007 Bucket Brigade IC chips to deliver the thickest, most luscious Chorus effect possible in pedal form, all while maintaining exceptional headroom. In addition to Speed and Depth knobs, the Supro Chorus features a Time control that increases the delay time on one side of the stereo field while shortening the delay time on the other side. Further increasing the available drama is a Dimension control, which mixes the stereo channels into one another for a mesmerizing intermingling of the two delay lines being modulated in opposite directions. A Vibrato switch removes the clean pass-through signal, allowing for pure pitch modulation with the Dimension knob, introducing a more complex, double vibrato effect. Runs on standard 9VDC.

Knob-by-Knob

• Depth: Sets the amount of modulation
• Speed: Sets the rate of modulation
• Time: Changes the delay time of both chorus channels in opposite directions
• Dimension: Mixes the two Chorus channels together
• Vibrato: Eliminates the clean signal from the effect for pure pitch modulation

Swimming in Sound Design

Featuring genuine Bucket Brigade IC chips, the Supro Chorus offers unimaginably luscious soundscapes, especially when played through a stereo amp setup.

Specifications

ELECTRONICS

• Power: 9VDC
• Current Draw: 100mA
• Input Impedance: 2.2M
• Output Impedance: 150ohms

BODY

• Length (in): 4.9
• Width (in): 3.2
• Height (in): 3.2
• Weight (lbs): 1
