Ortofon Replacement Spherical Stylus for Concorde MKII DJ Cartridge, Blue

Manufacturer’s Description

The Concorde DJ is considered the jack-of-all-trades, boasting accurate sound reproduction and excellent groove handling.

• The DJ is great for any style of music.
• It has a spherical stylus and an extremely balanced cantilever that provides outstanding rigidity.
• Not only does the cartridge have a most sufficient tracking ability, it also provides the DJs with the most needed stringency and very low record wear.
• All in all: improved tracking, alongside of accurate sound reproduction and an excellent groove handling.

Specifications

• Output voltage at 1000Hz, 5cm/sec. – 6 mV
• Channel balance at 1kHz – 1 dB
• Channel separation at 1kHz – 22 dB
• Channel separation at 15 kHz – 15 dB
• Frequency range at -3dB – 20-20.000 Hz
• Tracking ability at 315 Hz at recommended tracking force – 100 μm
• Compliance, dynamic lateral – 14 μm/m N
• Stylus type – Spherical R 18 μm
• Tracking force range – 3 – 5 g
• Tracking force recommended – 4 g
• Internal impedance, DC resistance – 700 Ohm
• Internal inductance – 450 mH
• Recommended load resistance – 47 kOhm
• Recommended load capacitance – 200-600 pF
• Cartridge weight – 18,5 g
• Replacement stylus unit – DJ
