Chauvet DJ CoDot ILS LED Illuminators

Manufacturer’s Description

CoDot ILS

• 4-pack of coin-sized LED illuminators that comes with over 15 accessories (1 carrying case, 8 lenses: 4 clear/4 diffused, 3 short USB-C cables, 3 long USB-C cables, 1 external power supply)
• Coin-sized LED illuminator designed for small applications where conventional fixtures won’t fit
• Includes two lens options to meet different application criteria
• Magnetic base easily mounts to metal surfaces
• Threaded insert is compatible with camera tripods and accessories
• ILS compatibility for use in the ILS ecosystem
• Built-in DFI transceiver communicates DMX or ILS signals wirelessly
• Built-in RF receiver for wireless control using the RFC or RFC-XL optional remotes
• Easy navigation and access all functions directly from the LED display
• Power linking multiple units from the USB type-C in and out

Specifications

• DMX Channels: 4 or 6
• Light Source: 1 LED (quad-color RGBW) 3 W, (0.8 A),
• 50,000 hours life expectancy
• Strobe Rate: 0 to 20 Hz
• Beam Angle (installed lens): 19°
• Beam Angle (included lens): 14°
• Illuminance (installed lens): 256 lux @ 2 m
• Illuminance (included Lens): 442 lux @ 2 m
• Max Unobstructed Distance: 600 ft (183 m)
• Operating Frequency: 2.4 GHz
• Power Linking: 4 units @ 120 V; 4 units @ 230 V
• Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-rang
• Power and Current: 7 W, 0.1 A @ 120 V, 60 Hz
• Power and Current: 7 W, 0.1 A @ 230 V, 50 Hz
• Weight: 0.2 lb (0.1 kg)
• Size: 2.2 x 2.1 x 0.9 in (57 x 54 x 24 mm)
• Optional Controllers: ILS Command, RFC, RFC-XL
• Approvals: CE, ROHS, UKCA, FCC
